TUI Guide¶
Pigit's primary interface is a terminal UI. Five core panels, plus diff detail and global overlays, cover everyday Git work.
Quick lookup
Press ? in any panel, or open the Keyboard Reference for a printable table.
Panels¶
| Panel | Keys | What you can do |
|---|---|---|
| Status | 1 | Stage / unstage / discard / ignore; inline commit; visual multi-select; tree view; side diff preview |
| Stash | 2 | Apply, pop, drop; diff preview |
| Branch | 3 | Checkout, create, merge, rebase, rename, delete; log graph preview; open PR page |
| Commit | 4 | Browse log; cherry-pick; another ref's history |
| Graph | 5 | Contribution heatmap, per-author chart, commits by hour |
Navigation¶
| Key | Action |
|---|---|
| J / K, Up / Down | Move selection |
| Enter | Select / open |
| Tab / Shift+Tab | Cycle panels |
| I | Inspector sheet for the current selection |
| Ctrl+P | Toggle side preview (Status/Stash diff or Branch log graph) |
Click a header tab slot to open an anchored panel picker. Click the repo name to switch managed repositories.
Status panel¶
| Key | Action |
|---|---|
| A | Stage file or visual selection |
| Shift+A | Stage all listed files |
| D | Discard |
| I | Ignore (add to .gitignore) |
| C | Inline commit editor (requires staged files) |
| Shift+C | Commit via external $EDITOR |
| M | Amend HEAD with staged changes |
| S | Stash with optional message (includes untracked) |
| V / Shift+V | Visual multi-select / visual scroll |
| Space | Toggle row (visual mode) |
| / | Filter files |
| Ctrl+T | Tree / flat layout |
| Y | Copy file path |
Commit editor¶
Opened with C when files are staged:
- Edit subject on the first line; body below the blank line.
- The lint bar flags common issues (empty subject, overlong line).
- Submit with Enter or cancel with Esc.
Diff viewer¶
Open from Status (Enter) or full-screen on wide layouts.
| Key | Action |
|---|---|
| H | Toggle hunk mode |
| S / D | Stage / discard hunk (hunk mode) |
[ / ] |
Previous / next hunk |
| , / . | Previous / next file in commit |
| V | File history (commit diffs) |
| P / N | Older / newer commit (file history) |
| Esc | Close |
Word-diff and syntax highlighting follow [app] word_diff in config.
Stash panel¶
| Key | Action |
|---|---|
| Enter | View stash diff |
| A | Apply (keep in list) |
| P | Pop |
| D | Drop (confirm) |
Push stash from Status with S (message prompt).
Commit panel¶
| Key | Action |
|---|---|
| C | Cherry-pick onto HEAD |
| O | Show another branch's log |
| Z | Toggle expanded commit rows |
| / | Filter by message or SHA |
| Y | Copy SHA |
Branch panel¶
| Key | Action |
|---|---|
| Enter | Show commits (no checkout) |
| C | Checkout |
| N | New branch |
| M | Merge current into selected |
| R | Interactive rebase onto selected branch |
| Shift+R | Rename |
| D | Delete |
| P | Open create-PR URL |
| Ctrl+F | Cycle local / remote / all |
Rebase sheet¶
Branch R opens the todo editor before git runs:
- Shift+J / Shift+K reorder commits
- P / S / F / R / E / D set pick / squash / fixup / reword / edit / drop
- Enter confirm
Graph panel¶
Three graphs, each carrying its own labels and legend: a contribution heatmap (which day), a per-author chart, and a punch card of commits by weekday and hour (what time of day). They lay themselves out side by side, wrapping onto further rows when the panel is too narrow for the next one.
| Key | Action |
|---|---|
| H / L, Left / Right | Pan left / right |
| J / K, Down / Up | Pan down / up |
| Ctrl+D / Ctrl+U | Pan half a screen |
| Home | Back to the first graph |
A mark on an edge means the graphs continue that way; the mouse wheel pans too.
Undo and recovery¶
| Key | Action |
|---|---|
| U | Reverse the most recent session action (with confirmation) |
| Shift+U | Browse the undo stack |
Undo covers staging, checkouts, merges, rebases, cherry-picks, and other
recorded HEAD moves. When nothing is available, the toast suggests
; reflog — see Workflows.
Multi-repo, worktree, bisect¶
| Feature | How to open |
|---|---|
| Repo switcher | Click header repo name or @ |
| Worktrees | Switcher → W → + / - to add/remove |
| Bisect | B → S start, G / B mark, R reset |
Bisect and sequencers (merge/rebase/cherry-pick) are mutually exclusive.
Help and welcome¶
- First run: Welcome sheet with panel map and core keys.
- Any time: ? opens the Help browser — click a row to select, double-click to run that binding.
TTY required
The TUI does not launch in CI pipelines, scripts, or when stdout is piped. See Troubleshooting.
